TTXS

Our TTXS Xtreme Series Connection, is a non-upset threaded and coupled connection which allows the pin ends to shoulder inside the coupling, resulting in a more cost-effective production string or liner. The flush bored connection provides increased flow rates with minimum turbulence, allowing for multiple make-and-breaks and unlimited recuts. The TTXS has special clearance sizes for use as liners to optimize production rates when production strings are leaking. Connection is 100% in tensile, compression, and internal pressure. Thread profile is rugged, faster to make-up, and stronger in tensile and compression than an API 8rd connection.

WHY TTXS?

AVAILABLE

  • 2 ⅜” OD to 9 ⅝” OD

APPLICATIONS

  • Production wells
  • Liner
  • Work-over wells
  • Special clearance

FEATURES

  • Non-upset ends
  • Threaded & coupled connection
  • 7TPI modified buttress thread form
  • Flush ID
  • Run-out thread

BENEFITS

  • Cost effective
  • Increased flow rate
  • Superior to 8-round connections
  • Robust thread design
  • 100% efficiency under tension/compression & internal pressure
  • Multiple make-and-breaks
  • Reduced erosion due to flush ID
  • Multiple re-cuts

FINITE ELEMENT ANALYSIS (FEA)

FEA was performed by a third-party independent engineering firm to confirm the design.

TORQUE-TO-YIELD

Torque-to-yield testing was performed to verify the torsional limits of the TTXS connections.

CONNECTION DATA SHEETS
